Mohawk MP-Series Mobile Column Lifts

MOHAWK MP-SERIES Mobile Column LIFT DESIGN

• Mohawk’s MP-Series Mobile Columns are built from heavy 5¾- or 7-inch U.S.-made forklift-channel steel, these columns outlast lifts made from bent sheet metal or tubing.
• Barrel-type roller bearings on the carriages ensure smooth, steady travel with no plastic slide blocks or rollers to wear out.
• Hydraulic actuation provides fast, efficient lifting without the friction of screw drives, and sealed rollers on the base make repositioning the columns quick and easy.
•  Standard operation uses 208–240 V three-phase power, with optional 440/460 V or single-phase setups.
  60 second lifting speed saves shops time and money.
• Communication and electrical cables disconnect at both ends for fast setup and storage, giving shops flexibility whether the lift is stationary or frequently moved.

MOHAWK’S PATENTED INDUSTRY-LEADING Mobile Column LIFT SAFETY SYSTEMS

• Each column includes 19 mechanical lock positions spaced every three inches, starting at 12 inches, plus locking pins on the adjustable forks for secure engagement.
• A low-mounted power unit keeps the center of gravity low for easier maneuvering, while dual pallet-jack style steering wheels drop under load to prevent unwanted movement.
• A manual safety override allows controlled lowering during a power outage—no hand cranks required.
• Mohawk builds the best heavy duty lifts, with the best warranty.

Wireless 24 V DC Operated Models

• For complete portability, Mohawk offers a wireless 24-volt DC version of the MP-Series lift.
• Each column is powered by twin 12-volt, deep-cycle, maintenance-free U.S.-made batteries and equipped with a 20-amp, gel-filled, 110-volt charger for quick recharging.
  • A single charge delivers 30 or more full lift cycles while still retaining 75 % battery capacity.
• These battery-operated columns feature the same heavy-duty construction, retractable wheels, adjustable lifting forks, and touchscreen controls as Mohawk’s AC-powered models, providing uncompromised lifting performance without the need for power cords.
